Pediatric Distal Radius Fracture - Double-Bend Titanium Elastic Nail

Score and Comment on this Case

Select a Score out of 10, and add a comment in the field below

Respectfully consider international variabilty in surgical technique and implants when commenting.
Protected by reCAPTCHA - Privacy and Terms

Clinical Details

Clinical and radiological findings:  A 7-year-old female presented following a fall from a bicycle, resulting in a left forearm injury. Radiographs revealed an off-ended distal radius fracture at the diaphyseal/metaphyseal transition zone, classified as AO/OTA 23-M/2. The ulna demonstrated a distal buckle fracture. This was a closed injury with neurovascular status intact.

Preoperative Plan

Planning remarks:  The preoperative plan involved a closed reduction attempt of the distal radius fracture under fluoroscopic guidance. Given the significant radial translation of the distal radial fragment, the plan included the use of a titanium elastic nail (TEN) for stabilization if closed reduction was insufficient.

Surgical Discussion

Patient positioning:  The patient was positioned supine on a radiolucent operating table, with her left arm placed to the side on an auxiliary table.

Anatomical surgical approach:  A five-millimeter skin incision was made at the distal radial metaphysis, followed by blunt dissection down to the periosteum. An entry point for the nail was created using a four-point trochar. A 2.5 millimeter titanium elastic nail, pre-bent at its distal end, was introduced into the medullary canal. The nail was advanced proximally across the fracture site, achieving three-point fixation and facilitating dynamic reduction.

Operative remarks:

The reduction was confirmed in two planes using fluoroscopy. The elastic nail was trimmed within the subcutaneous tissue, and the wound was irrigated and closed with interrupted 4-0 nylon sutures. A below-the-elbow fiberglass splint was applied to immobilize the forearm.

Postoperative protocol:   Not specified

Follow up:   Not specified

Orthopaedic implants used:   2.5mm Titanium Elastic Nail
